Parameter Number Parameter Description Default Value 2 Setup Change During Operation Conversion Index Type 3 - 00 Reference Range [0] Min - Max All set-ups TRUE - Uint8
3 - 02 Minimum Reference
0 All set-ups TRUE
-3 Int32
3 - 03 Maximum Reference 50 All set-ups TRUE -3 Int32
3 - 10 Preset Reference
0% All set-ups TRUE
-2 Int16
3 - 11 Jog Speed [Hz] 5 Hz All set-ups TRUE -1 Uint16
3 - 12 Catch up/slow Down Value
0% All set-ups TRUE
-2 Int16
3 - 14 Preset Relative Reference 0% All set-ups TRUE -2 Int16
3 - 15 Reference Resource 1
[1] Analog in 53 All set-ups TRUE
- Uint8
3 - 16 Reference Resource 2 [2] Analog in 60 All set-ups TRUE - Uint8
3 - 17 Reference Resource 3
[11] Local bus reference All set-ups TRUE
- Uint8
3 - 18 Relative Scaling Reference Resource [0] No function All set-ups TRUE - Uint8
3 - 40 Ramp 1 Type
[0] Linear All set-ups TRUE
- Uint8
3 - 41 Ramp 1 Ramp up Time 3 s All set-ups TRUE -2 Uint32
3 - 42 Ramp 1 Ramp Down Time
3 s All set-ups TRUE
-2 Uint32
3 - 50 Ramp 2 Type [0] Linear All set-ups TRUE - Uint8
3 - 51 Ramp 2 Ramp up Time
3 s All set-ups TRUE
-2 Uint32
3 - 52 Ramp 2 Ramp down Time 3 s All set-ups TRUE -2 Uint32
3 - 80 Jog Ramp Time
3 s All set-ups TRUE
-2 Uint32
3 - 81 Quick Stop Ramp Time 3 s 1 set-up TRUE -2 Uint32
5.2.8. 3-** Reference/Ramps
VLT
p
Micro Drive FC 51 5. Parameter Lists
MG.02.C4.02 - VLT
p
is a registered Danfoss trademark 71
5
