Parameter Number Parameter Description Default Value 2 Setup Change During Operation Conversion Index Type 6 - 00 Live Zero Timeout Time 10 s All set-ups TRUE 0 Uint8
6 - 01 Live Zero TimeoutFunction
[0] Off All set-ups TRUE
- Uint8
6 - 10 Terminal 53 Low Voltage 0.07 V All set-ups TRUE -2 Uint16
6 - 11 Terminal 53 High Voltage
10 V All set-ups TRUE
-2 Uint16
6 - 12 Terminal 53 Low Current 0.14 mA All set-ups TRUE -2 Uint16
6 - 13 Terminal 53 High Current
20 mA All set-ups TRUE
-2 Uint16
6 - 14 Terminal 53 Low Ref./Feedb. Value 0 All set-ups TRUE -3 Int32
6 - 15 Terminal 53 High Ref./Feedb. Value
50 All set-ups TRUE
-3 Int32
6 - 16 Terminal 53 Filter Time Constant 0.01 s All set-ups TRUE -2 Uint16
6 - 19 Terminal 53 mode
[0] Voltage mode 1 set-up TRUE
- Uint8
6 - 22 Terminal 60 Low Current 0.14 mA All set-ups TRUE -2 Uint16
6 - 23 Terminal 60 High Current
20 mA All set-ups TRUE
-2 Uint16
6 - 24 Terminal 60 Low Ref./Feedb. Value 0 All set-ups TRUE -3 Int32
6 - 25 Terminal 60 High Ref./Feedb. Value
50 All set-ups TRUE
-3 Int32
6 - 26 Terminal 60 Filter Time Constant 0.01 s All set-ups TRUE -2 Uint16
6 - 81 LCP potentiometer Low Ref.
0 All set-ups TRUE
-3 Int32
6 - 82 LCP potentiometer High Ref. 50 All set-ups TRUE -3 Int32
6 - 90 Terminal 42 Mode
[0] 0-20 mA All set-ups TRUE
- Uint8
6 - 91 Terminal 42 Analog Output [0] No operation All set-ups TRUE - Uint8
6 - 92 Terminal 42 Digital Output
[0] No operation All set-ups TRUE
- Uint8
6 - 93 Terminal 42 Output Min Scale 0% All set-ups TRUE -2 Uint16
6 - 94 Terminal 42 Output Max Scale
100% All set-ups TRUE
-2 Uint16
5.2.11. 6-** Analog In/Out
5. Parameter Lists VLT
p
Micro Drive FC 51
74 MG.02.C4.02 - VLT
p
is a registered Danfoss trademark
5
