Danfoss VLT User Manual

[1835] Analog Out X42/11 [V]
[1850]
[2117] Ext. 1 Reference [Unit]
[2118] Ext. 1 Feedback [Unit]
[2119] Ext. 1 Output [%]
[2137] Ext. 2 Reference [Unit]
[2138] Ext. 2 Feedback [Unit]
[2139] Ext. 2 Output [%]
[2157] Ext. 3 Reference [Unit]
[2158] Ext. 3 Feedback [Unit]
[2159] Ext. 3 Output [%]
[2230] No-Flow Power
[2316] Maintenance Text
[2580] Cascade Status
[2581] Pump Status
[3110] Bypass Status Word
[3111] Bypass Running Hours
[9913] Idle time
[9914] Paramdb requests in queue
[9920] HS Temp. (PC1)
[9921] HS Temp. (PC2)
[9922] HS Temp. (PC3
[9923] HS Temp. (PC4)
[9924] HS Temp. (PC5)
[9925] HS Temp. (PC6)
[9926] HS Temp. (PC7)
[9927] HS Temp. (PC8)
0-22 Display Line 1.3 Small
Option: Function:
Select a variable for display in line 1, right position.
[1610] * Power [kW]
The options are the same as those listed for par. 0-20
Display Line 1.1 Small .
0-23 Display Line 2 Large
Option: Function:
Select a variable for display in line 2.
[1613] * Frequency [Hz]
The options are the same as those listed for par. 0-20
Display Line 1.1 Small .
0-24 Display Line 3 Large
Option: Function:
[1602] * Reference % Select a variable for display in line 3. The options are the same as listed for par. 0-20.
VLT
®
HVAC Drive Instruction Manual
6 How to program the adjustable frequency
drive
MG.11.A9.22 - VLT
®
is a registered Danfoss trademark 6-19
6

Danfoss VLT Specifications

General

Frequency	50/60 Hz
Enclosure	IP20, IP21, IP55, IP66
Series	VLT
Control Technique	Flux Vector Control
Output Voltage	0-Vinput
Control Method	Fieldbus
Communication Interface	PROFIBUS, CANopen
Protection Features	Overload, Overvoltage, Undervoltage, Short Circuit, Ground Fault
Cooling Method	Liquid Cooled
Storage Temperature	-25°C to +70°C
Relative Humidity	5-95% non-condensing
Altitude	Up to 1000m (3280ft) without derating, up to 4000m (13120ft) with derating
Operating Temperature	-10°C to +50°C (14°F to 122°F)
