Danfoss VLT5000 SyncPos User Manual

Programmable SyncPos motion controller
MG.10.J8.02 – VLT is a registered Danfoss trade mark
214
Program samples
■■
■■
■ Program samples
■■
■■
■ Introduction
WARNING!
The entire unit must be installed according
to the installation instructions and the
functionability of the individual components and
connections must be tested.
An EMERGENCY STOP must be installed accor-
ding to the specific guidelines of the respective
country.
The program samples may only be used with a
drive which can turn freely without a path limi-
tation.
The drive should be fixed in a stable holding
device.
When using a linear unit limit switches for path
limitation must be mounted and connected.
When using a linear unit the area of movement of
the program samples must be calculated roughly
and compared with the paths of movement which
are mechanically permissible.
Cross references to the online help program
samples
In the online help you will find all the other pro-
gram samples, which are mentioned in the chapter
software reference. You can copy these programs
or parts of them directly into your program.

Danfoss VLT5000 SyncPos Specifications

General

Category	Controller
Frequency	50/60 Hz
Series	VLT5000
Control Method	Vector control
Communication	CANopen
Enclosure Rating	IP20
Storage Temperature	-25°C to 70°C
Altitude	Up to 1000m above sea level
Humidity	5% to 95% (non-condensing)
