8 Device description
8.1 Difference BASIC / W-BUS / E-BUS
The versions are supporting different output signals as shown at the table.
output signal / Version output
BASIC W-BUS E-BUS PIN
+12V +12V +12V 2
ground ground ground 3
+12V W-BUS 3 E-BUS 3 1
W-BUS 4 E-BUS 4
W-BUS 5 E-BUS 5
W-BUS 6 E-BUS 6
E-BUS 7
E-BUS 8
9 - 32
The APP-control "W-BUS" and "E-BUS" are supporting
different output signals. An overview about the signal
needed for your vehicle or heater
can be found at our website: www.danhag.de
