3�4 PLUMBING
IMPORTANT
Before installing e heat pump ensure e
blanking disks are removed from e pool water
in/out connections� These should drop out when
e adaptors are unscrewed�
1. Ensure at bypass is installed and set to achieve
e recommended flow rates stated in e data
sheet.
2. Ensure at e condensate drain kit supplied is
fixed and is drained to a drain or soak-away.
(It is best to do is first before e heat pump
is fixed to pipework or e ground)�
3. Inlet and outlet pipework must be supported to
avoid excessive strain on e connections.
4. Water quality must be maintained. See warranty
conditions.
Note: Fittings shown at larger scale for clarity.
Hose. Condensate adaptor.
Fit in hole in base of unit.
Approximate position shown.
Water
out
Water
in
3�5 INITIAL CHECKS
Start e filtration pump before e heat pump is
turned on, and turn off e heat pump before e
filtration pump. It is recommended to turn off e heat
pump prior to backwashing.
Before starting e heat pump, please check for
any leakage of water; and check/set e required
temperature on e controller, and en turn on.
In order to protect e components, e heat pump
incorporates time delays. When starting heating/cooling
e fan will run for one minute before e compressor
starts. When e heat pump stops heating/cooling, or
is turned off by e user, e fan will continue to run for
one minute.
Aer starting up, check for any error codes or abnormal
noise from e heat pump.
