36
1007332 ISSUE 1
OWNER/INSTALLATION MANUAL
8�0 DATASHEETS
MODEL UNITS HPP-i 8 HPP-i 12 HPP-i 16
PERFORMANCE CONDITION: Air 27°C/Water 27°C/RH 80%
Heating capacity kW 9.5 13.0 20.0
COP range 13.2-5.4 13.5-5.6 13.5-5.7
Average COP at 50% Speed 8.9 9.7 9.3
PERFORMANCE CONDITION: Air 15°C/Water 26°C/RH 70%
Heating capacity kW 7.0 9.5 13.5
COP range 6.9-4.2 7.0-4.0 7.0-4.2
Average COP at 50% Speed 6.3 6.1 6.3
PERFORMANCE CONDITION: Air 35°C/Water 28°C/RH 80%
Cooling capacity (kW)
3.9 5.2 7.4
TECHNICAL SPECIFICATIONS
Operating air temperature °C -5°C to 43°C
Water heat temperature set range °C 18°C to 40°C
Water cool temperature set range °C 12°C to 30°C
POWER SUPPLY 230V Single Phase 50Hz
Rated input power kW 0.3-1.79 0.40-2.38 0.57-3.21
Rated input current A 1.38-7.58 1.82-10.8 2.60-14.61
Maximum input current A 9.5 12.5 19.5
Rated RCD type F
mA 30 30 30
Rated Fuse aM / MCB type C A 16 16 25
Sound pressure level at 10m dB(A) 19.6-31.5 21.9-32.0 24.3-36.1
Recommended water flow rate m
3
/h 3.0-5.0 4.0-6.0 7.0-10.0
Pressure drop m/kPa 0.36/3.5 0.41/4.0 0.56/5.5
Pool water connections Inches 1½” or 50mm Female
GENERAL DATA
Net dimensions (w x d x h) mm 864 x 359 x 648 864 x 359 x 648 954 x 359 x 748
Packed dimensions (w x d x h) mm 950 x 375 x 675 950 x 375 x 675 1040 x 375 x 775
Net weight kg 47 49 68
HERMETIC SYSTEM
Refrigerant charge R32 kg 0.6 0.9 1.1
Minimum area requirement m2 3.1 6.9 10.3
NOTES: Heat pump performance parameters are subject to change wiout notice. Always refer to e
nameplate. Global warming potential (GWP) R32 - 675.
The data is subject to modification wiout prior warning.
