Dantherm HPP-i 8 User Manual

18
1007332 ISSUE 1
OWNER/INSTALLATION MANUAL
L N
Fuse/MCB
Eared Power
Supply 230V 50Hz
Supply
cord
Distribution box
L N
RCD/
Circuit
Breaker
P1 P2
Power
terminals
Pump
terminals
Cable clamp
Single phase
Terminals in Heat Pump Electrics enclosure
Isolator which
disconnects all poles
fitted wiin 2m and in line
of sight of e heat pump
Secure cables
using cable clamps
and feed rough
cable entry points in
machine
Isolator which
disconnects all poles
fitted wiin 2m and in line
of sight of e heat pump
L3
N
Fuses/MCB
Eared Power
Supply 400V 50Hz
L3 N P1 P2
Power
terminals
Pump
terminals
L2
L1
L2
L1
Three phase
Terminals in Heat Pump Electrics enclosure
Cable clamp
Supply
cord
RCD/
Circuit
Breaker
Distribution box
Secure cables
using cable
clamps and feed
rough cable
entry points in
machine
Remove ese
two screws
Li lower
panel away
1
Remove ese
four screws and
remove cover
Two cable
entry points
2
3�8 CONNECTING THE HEAT PUMP TO THE
POWER SUPPLY
