21
1007332 ISSUE 1
If e cable is concealed, fit e grommet in e hole to
protect e cable from rubbing.
Secure e cable from e controller in e HPP-i.
Refit e front cover and e top cover.
To check at e installation is correct, set e
temperature on e remote controller to slightly higher
an e pool water. The HPP-i should run to heat
e pool, immediately if e pump synchronisation
is not in use, or at e next sampling period if pump
synchronisation is in use.
Inlet for
exposed cable.
Inlet for
concealed cable.
Connect e lead. Connect e lead.
Remove e two screws from e back of e Remote
Controller.
Remove e appropriate knock out and fit e back of
e box to e wall.
