Rack Mounting
The device can be mounted in a standard 19-inch rack. The device requires 1 rack unit (U) of space,
which is 44,5 mm high.
Make sure that the rack is sufficiently secured to prevent it from becoming unstable or falling over.
To mount the device in a two-post rack, follow the steps below:
01) Insert 4 cage nuts in the openings on the rack posts where you want to mount the device.
02) Position the device in front of the rack posts so that the 4 x mounting openings (01) on the flanges
face the openings on the rack posts with cage nuts.
03) Using a screwdriver, mount the device to the rack posts with 4 screws.
Note: Make sure that the FM/DAB+ antenna points up.
Connecting to Power Supply
The device accepts AC mains power at 220–240 V and 50 Hz. Do not supply power at any other voltage
or frequency to the device.
The device is equipped with the input voltage selector (20) that can be used for selecting of the input
voltage. Only skilled persons are allowed to operate the input voltage selector (20). The selector is, by
default, set to 230 V AC 50 Hz.
This device falls under IEC protection class I. Make sure that the device is always electrically connected
to the ground (earth).
Before connecting the device to the socket-outlet:
● Make sure that the power supply matches the input voltage specified on the information label on
the device.
● Make sure that the socket-outlet has ground (earth) connection.
Connect the device to the socket-outlet with the power plug.
Start-up
To connect and use the device, follow the steps below:
Make sure that the device is switched off. See 4.6.2. Switching On/Off on page 13 for more
information.
Connect the DAB+/FM antenna to the DAB+/FM antenna connector IN (21) and extend the
antenna.
Connect input and output devices. See 4.6.1. Setup Example on page 12.
● To connect an amplifier, use the RCA analog line-level connectors OUT (17), the unbalanced 6,3
mm TS jack line-level connectors OUT (18) or the balanced 3-pin XLR line-level connectors OUT
(19).
● To connect a smartphone, MP3 player or a laptop, use the balanced 3,5 mm TRS jack connector
AUX IN (07). When this connector is in use, the internet radio will be muted.
● To connect a dynamic microphone, use the XLR/6,3 mm jack combo microphone connector IN
(15).
● To connect a CD player or a tuner, use the (Line 1–4) RCA analog line-level connectors IN (16).
Turn the input selector (08) to set the input source.
Switch on the input devices (e.g. audio mixer, CD player).
Switch on the device. See 4.6.2. Switching On/Off on page 13 for more information.
