DataCard SD360 User Manual

92 Card Design Tasks
Print Mode Tab
The Print Mode tab allows you to specify the print resolution to use when printing a card.
For card printers that support printing to rewritable cards, use the Print Mode tab to tell the
printer to use the rewrite feature. Refer to “Select the Rewrite Option” on page 93.
Select the Print Resolution
1. Open the Printing Preferences
window.
2. Select the Print Mode tab.
3. Select the desired print resolution. The
Print Mode tab has the following three
options.
 Always use standard resolution
(300x300 dpi)—This is the default
selection.
 Always use best possible
resolution
 Custom—The Custom option
allows you to select a resolution
from the Color and Monochrome
drop-down lists.
4. Click Apply to save your changes, and
then click OK to close the Printing Preferences window.
The Print Mode tab does not display for the following printers:
 CR805 retransfer card printer. The printer always prints with a resolution of
600 x 600 dpi.
 CE840 system, if the printer does not have a printhead installed.

DataCard SD360 Specifications

General

Card size	85.6 x 53.98 mm
Card types	Magnetic stripe (ISO 7811), PVC
Card feeder	Yes
Print technology	Dye-sublimation
Maximum resolution	300 x 300 DPI
Print speed (color)	200 card/h
Print speed (monochrome)	830 card/h
Duplex print speed (color)	155 card/h
Display	LCD
Lamination	No
Certification	cULus, FCC, I.C, CE, Ctick, VCCI, RoHS, WEEE, ENERGY STAR, CCC
Product color	Black, Blue
Internal memory	128 MB
Built-in barcodes	1D, 2D
Cable lock slot type	Kensington
Total input capacity	100 sheets
Compatible operating systems	Windows Server 2003/Server 2008
Windows operating systems supported	Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	15 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Interface	USB & Ethernet

Weight and Dimensions

Weight	5400 g
Dimensions (WxDxH)	175 x 539 x 224 mm
