Before using split-ribbon color printing, be aware of the following:
 Set up your card design with your card production software or a PC application as you
normally do.
 Select a split-ribbon option that applies topcoat to the side of the card where any color
printing is used. If you use a laminating system, make sure that you set up your lamination
options to apply an overlay to the side of the card with color printing. Refer to “Lamination
Tab” on page 94 for information about specifying lamination options.
 Install the correct ribbon type in your printer. The split-ribbon option is ignored if the ribbon
installed in the printer does not match the selection in the Printing Preferences Advanced
Options window.
 When the split-ribbon option specifies only color for a card side (for example, YMCT-K), any
black text or monochrome images (including bar codes) on that side of the card are printed
using the color panels to simulate black.
If short-panel color ribbon is installed in the printer, make sure that your card design does not
have any black elements on the front side of the card that will print before the color
elements. The ribbon split will begin printing the black element using the color panels of the
ribbon, resulting in the color elements possibly not printing completely.
YMCK K-YMC
 black (K) back
 color (YMC) back
Note: This ribbon type does not include a topcoat panel
and is meant to be used with a laminator, which can apply
an overlay to one or both sides of the card.
YMCKT-K K-YMCKT
 black (K) front
 color (YMC) + black (K) + topcoat (T) back
YMCKT-KT KT-YMCKT
 black (K) + topcoat (T) front
 color (YMC) + black (K) + topcoat (T) back
YMCKT-KT YMCKTT-K
 color (YMC) + black (K) + two topcoat panels (TT) front
 black (K) back
YMCKF-KT YMCKFT-K
 color (YMC) + black (K) + UV (F) + topcoat (T) front
 black (K) back
MT-KT MTT-K
 monochrome (M) + two topcoat panels (TT) front
 black (K) back
Ribbon Type Split Option Description

DataCard SD360 Specifications

General

Card size	85.6 x 53.98 mm
Card types	Magnetic stripe (ISO 7811), PVC
Card feeder	Yes
Print technology	Dye-sublimation
Maximum resolution	300 x 300 DPI
Print speed (color)	200 card/h
Print speed (monochrome)	830 card/h
Duplex print speed (color)	155 card/h
Display	LCD
Lamination	No
Certification	cULus, FCC, I.C, CE, Ctick, VCCI, RoHS, WEEE, ENERGY STAR, CCC
Product color	Black, Blue
Internal memory	128 MB
Built-in barcodes	1D, 2D
Cable lock slot type	Kensington
Total input capacity	100 sheets
Compatible operating systems	Windows Server 2003/Server 2008
Windows operating systems supported	Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	15 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Interface	USB & Ethernet

Weight and Dimensions

Weight	5400 g
Dimensions (WxDxH)	175 x 539 x 224 mm
