DM4270 – Installation Guide
Hardware DESCRIPTION
204.4331.03 - October/2019
11
Description
1
SLOT PSU1
2
PSU 400 AC Handle
3
PSU 400 AC Power Input
4
PSU 400 AC Status LED
5
PSU 400 AC Insertion and Removal Latch
6
PSU2 SLOT
7
PSU 400 DC Handle
8
PSU 400 DC Power Input
9
PSU 400 DC Status LED
10
PSU 400 DC Knurled nut
11
Ethernet Management Port
12
RS-232 Console Port
13
Alarm interface (2 inputs and 1 output)
14
System ALARM/FAIL LED
15
USB Port Console
16
40/100GE Ethernet LED ports
17
40GE Ethernet LED ports
18
10GE Ethernet ports
19
10GE Ethernet port LEDs
20
40/100GE Ethernet ports
21
40GE Ethernet ports
22
Equipment cooling outlets
23
Host USB Port
24
Auxiliary Safety Grounding
25
Power Supply cooling outlets
Table 1 – DM4270 24XS+2CX Interface Description
