Datakom DKG-109 - Input Configuration (Switches)

DKG-109 User Manual V-27 (23.08.2013)
- 37 -
Program Group: Input Configuration (Low Oil Pressure Switch)
(password level-2)
Parameter Definition
Unit
Factory
Set
Description
Action
0
0: Shutdown (the engine stops immediately)
1: Load Dump (the engine stops after cooldown)
2: Warning (the horn relay operates)
3: No operation
Sampling
1
0: Always
1: After holdoff timer
2: When mains present
Latching
1
0: Non latching
1: Latching
Contact type
0
0: Normally open
1: Normally closed
Switching
0
0: Battery negative
1: Battery positive
Response delay
0
0: No delay
1: Delayed (4sec)
Program Group: Input Configuration (High Temperature Switch)
(password level-2)
Parameter Definition
Unit
Factory
Set
Description
Action
0
0: Shutdown (the engine stops immediately)
1: Load Dump (the engine stops after cooldown)
2: Warning (the horn relay operates)
3: No operation
Sampling
1
0: Always
1: After holdoff timer
2: When mains present
Latching
1
0: Non latching
1: Latching
Contact type
0
0: Normally open
1: Normally closed
Switching
0
0: Battery negative
1: Battery positive
Response delay
0
0: No delay
1: Delayed (4sec)
