Datakom DKG-109 - Input Function Select

DKG-109 User Manual V-27 (23.08.2013)
- 41 -
The parameters below define the functions of digital inputs, selected from a list.
Functions from 12 to 23 activate also the related operating sequence.
The related input configuration parameters apply for each input, thus any signal can be
programmed for NO or NC contact, closing to BAT+ or BAT-.
Program Group: Input Function Select (password level-2)
Parameter Definition
Fact.
Set
Description
Input 01 Function Select
0
Oil Pressure Switch
Input 02 Function Select
1
High Temp. Switch
Input 03 Function Select
4
Emergency Stop
Input 04 Function Select
11
Spare-1 Input
Input 05 Function Select
10
Spare-2 Input
Input Function Select List
Number
Description
0
Oil Pressure Switch
1
High Temp. Switch
2
Low Coolant Level switch
3
Rectifier Fail
4
Emergency Stop
5
Alternator High Temp.
6
Door Open
7
Low Fuel Level Switch
8
Earthquake Detector
9
Spare-3 Input
10
Spare-2 Input
11
Spare-1 Input
12
Force AUTO Mode
13
Force OFF Mode
14
Force TEST Mode
15
Force LOAD TEST Mode
16
2nd Volt-Freq Select
17
Priority Input
18
Remote Start Input
19
Disable Auto Start
20
Force to Start
21
Fault Reset
22
Alarm Mute
23
Panel Lock
