Datakom DKG-509 User Manual

DKG-509 User Manual V-29 (23.08.2013)
- 9 -
Screen
Description
Contents
1
Mains parameters
(phase to neutral)
Genset status
Mains Volts L1, Mains Frequency
Mains Volts L2 , Battery Voltage
Mains Volts L3, Coolant Temperature
2
Mains parameters
(phase to phase)
Genset status
Mains Volts L1-L2, Mains Frequency
Mains Volts L2-L3, Battery Voltage
Mains Volts L3-L1, Coolant Temperature
3
Genset parameters
(phase to neutral)
Genset status
Genset Current L1, Genset Frequency
Genset Current L2, Genset Active Power (KW)
Genset Current L3, Genset Volts L1
4
Genset parameters
(phase to phase)
Genset status
Genset Current L1, Genset Frequency
Genset Current L2, Genset Active Power (KW)
Genset Current L3, Genset Volts L1-L2
5
Engine parameters
Genset status
Oil Pressure, Engine rpm
Coolant Temperature, Battery Voltage
Fuel Level,
6
Complete Genset
parameters
(phase to neutral)
Genset status
Genset Volts L1, Genset Volts L2, Genset Volts L3
Genset Current L1, Genset Current L2, Genset Current L3,
Genset Frequency, Oil Pressure
Genset Active Power (KW), Coolant Temperature
Genset power factor, Fuel Level
Engine rpm, Battery Voltage
7
Complete Genset
parameters
(phase to phase)
Genset status
Genset Volts L1-L2, Genset Volts L2-L3, Genset Volts L3-L1
Genset Current L1, Genset Current L2, Genset Current L3
Genset Frequency, Oil Pressure
Genset Active Power (KW), Coolant Temperature
Genset power factor, Fuel Level
Engine rpm, Battery Voltage
8
Graphical Genset
parameters
(phase to neutral)
Genset status
Genset Current L1
Genset Volts L1
Genset Active Power (%), Genset Frequency
Oil Pressure
Coolant Temperature
Fuel Level
9
Graphical Genset
parameters
(phase to phase)
Genset status
Genset Current L1
Genset Volts L1-L2
Genset Active Power (%), Genset Frequency
Oil Pressure
Coolant Temperature
Fuel Level
10
Genset Phase Power
parameters
Genset status
Genset Phase L1 : Active Power(KW) / Power Factor
Genset Phase L2 : Active Power(KW) / Power Factor
Genset Phase L3 : Active Power(KW) / Power Factor
