xiii
DS5100-X300
Built-in Ethernet Models
Figure B
1
Warning and Device Class Labels
7
Indicator LEDs
2
Power – Serial Interfaces – I/O Connector
8
Network LEDs
3
Ethernet Connector
9
Power On LED
4
Laser Beam Output Window
10
Focus Adjustment Screw
5
Mounting Holes (7)
11
X-PRESS™ Push Button
6
Display
Connector block rotates to 90° position.
9
6
10
11
8
2
4
5
7
1
3
5
