Datalogic DS5100 - Page 15

xv
DS5100-XX20
OM Models
Figure D
1
Warning and Device Class Labels
7
Indicator LEDs
2
Power – Serial Interfaces – I/O Cable
8
Network LEDs
with 25-pin D-sub connector
9
Power On LED
4
Laser Beam Output Window
10
Focus Adjustment Screw
5
Mounting Holes (7)
11
X-PRESS™ Push Button
6
Display
4
1
6
7
8
9
11
10
2
5
