PROGRAMMABLE 2D SYMBOLOGIES
Aztec Code
Code
Parameter
Description
I.D.#
Accept.
Input
Defaults
Scanner
Type
Min
Max
Factory
2D Imager
Enter 1 for On and 0 for Off
Aztec
Code
Enable
Enables/disables the Aztec
symbology.
0B18 On or Off Off On On √
Aztec
Code Minimum
Set the minimum bar code
label length to be less
than or equal to maximum
label length.
0B2C 1-3750 1 3750 1 √
Aztec
Code
Maximum
This feature specifies the
maximum allowable length
of a label. The length
includes check and data
characters, if applicable.
Maximum Label Length
should be greater than or
equal to Minimum Label
Length.
0B2D 1-3750 1 3750 3750 √
Aztec
Code User
ID
Specifies the symbology
identifier (if any) that is
sent when parameter
Send Code ID (Index
0025) is set to 3. ASCII
code zero (null) is used to
indicate that an identifier
is not to be sent for the
symbology.
0B2F
Any
single
ASCII
character
(00 = Off)
‘d’ ‘d’ ‘d’ √
