Quick Reference Guide 3
Volume/Tone Push Button
The Volume/Tone Push Button (Figure 2d — accessed by removing the Top
Cover
Figure 2c) also performs multiple functions depending upon the duration
of time it is pressed:
NOTE
Volume changes made using the Volume/Tone Push Button are lost
when the scanner is powered-down and are reset to the configured set-
ting. If you wish to permanently change the volume, use the special
programming labels in the Product Reference Guide.
Table 1. Volume/Tone Push Button Functions
PRESS
DURATION
FUNCTION COMMENT
Momentary (when
scanner is asleep)
Wakes scanner from Sleep
Mode
Alternatively, the scanner can be awakened by:
- Moving an object through the scan zone.
- Scanning with an attached auxiliary scanner.
Momentary (when
scanner is awake)
Increments volume
Press the push button momentarily to increase speaker vol-
ume. When the loudest volume is reached, a repeated press
of the push button cycles volume back to the lowest setting,
then volume increases on subsequent press(es). Four volume
levels are available.
Hold, then release
when the beeper
sounds
Increments tone
Press the push button for approximately 2 seconds, then
release. Each time this is done, the beeper will sound at one
of three tones. Stop when the desired tone (high, medium or
low) is sounded.
4 Seconds
Scanner Diagnostics Mode
a
This mode allows system support personnel to troubleshoot
problems with the scanner and is used to determine if it can
read bar codes. Press the button for eight seconds or cycle
power to exit Scanner Diagnostics Mode and reset the scan-
ner.
8 Seconds
Resets Scanner
b
Only system support personnel should perform a reset.
a. By standard default, this function is normally disabled to prevent accidental activation by users.
b. Users should not perform scanner resets except under the direction of trained systems support person-
nel.
