Quick Reference Guide 1
Quick Reference
Use this guide to quickly complete your installation and begin
using your scanner. For more details, including programming
information, reference the Product Reference Guide (PRG),
which is available for viewing and download from the Datalogic
website listed on the back cover of this manual.
Labeling and Nomenclature
Figure 1. Labeling and Nomenclature
1. Top Cover 2. Speaker Port
3. Cover Removal Indentation 4. Push Button
5. Label 6. Lift Handles
7. LED Indicator 8. Cable Cover
9. SD Card Slot
1
2
3
4
6
8
7
9
5
