Datalogic Magellan 3300HSi Quick Reference Guide

Quick Reference Guide 5
Productivity Index Reporting™ Option
Your scanner may be equipped with the optional Productiv-
ity Index Reporting
™
feature. This feature allows for data
collection on the readability index of bar codes scanned by
the scanner. This data may be transmitted to the POS Ter-
minal where it may be easily sorted for action by the MIS
department to improve bar code quality at the front end.
For additional information on how to enable Productivity
Index Reporting in your scanner, please refer to the Product
Reference Guide (PRG)
Scanner Push Button
The Scanner Push Button also performs multiple functions
depending upon the duration of time it is pressed:
NOTE
Volume changes made using the Volume/Tone Push
Button are lost when the scanner is powered-down
and are reset to the configured setting. If you wish to
permanently change the volume, use the special
programming labels in the Product Reference Guide.
Table 1. Scanner Push Button Functions
PRESS
DURATION
FUNCTION COMMENT
Momentary (when
scanner is asleep)
Wakes scanner from
Sleep Mode
Alternatively, the scanner can be
awakened by:
- Moving an object through the
scan zone.
- Scanning with an attached aux-
iliary scanner.

Datalogic Magellan 3300HSi Specifications

General

Scanner type	1D
Decoding standards	GS1, MicroPDF417, PDF417
Optical sensor resolution	1280 pixels
Light levels (direct sunlight)	0 - 86100 lx
Dimensions (WxDxH)	152 x 87 x 152 mm
Power consumption (active)	9.9 W
Standard interfaces	USB, RS-232
Input voltage	90 - 264 V
Power requirements	47 - 63 Hz
Power consumption (standby)	2 W
Certification	RoHS, EN 60825-1, IEC 60825, IEC 60825-1
Product color	Stainless steel
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Weight	790 g
