2-18 Magellan
®
8300/8400
• Carefully lift off the L-Platter as shown in Figure 2-22 and remove
the protective foam pieces securing the weigh mechanism. Set the
platter back in place.
NOTE
For added protection during shipment, the L-Platter is covered with a tight-
fitting layer of vinyl. This vinyl layer MUST BE REMOVED before placing the
unit into service.
