Interface Related Features

Technical Guide 5-13

Interface Type — continued

To select the desired interface:

1. Disconnect current interface cable(s) if currently connected.

2. Scan the SWITCH bar code

3. Scan the bar code representing the appropriate interface located on

the following pages. You’ll need to cover any unused bar codes adja-

cent to and on any facing pages to ensure the scanner reads only the

bar code you intend to scan.

NOTE

A new scanner may have been shipped from the factory with a Null Interface

(no interface type selected) to ensure system compatibility at installation. In

this case, the correct Interface Type programming bar code must be scanned

first before the scanner can be used with a POS system.

NOTE

If the scanner’s interface type must be changed, always be sure that interface

configuration is the FIRST item scanned during a programming session.

(Selecting an interface type resets ALL other configuration items to the fac-

tory default for that interface type.)

CAUTION

Great care should be taken to select the correct interface type, since you can

cause damage to the scanner and/or POS terminal by attempting to change

to an incompatible interface. ALWAYS make interface selections with the

host cable DISCONNECTED.

NOTE

When an interface is selected, the scanner loads the factory configuration

for that interface as the selection is made, erasing any and all custom config-

uration that may have previously been done.
