MATRIX-2000™ QUICK GUIDE
6
C-BOX 100 Pinout for Matrix-2000™
The table below gives the pinout of the C-BOX 100 terminal block connectors. Use this pinout when the Matrix-
2000™ reader is connected by means of the C-BOX 100:
C-BOX 100 Terminal Block Connectors
Power
1, 3, 5 VS
2, 4, 6 GND
7, 8 EARTH GROUND
20, 40 Reserved
Inputs
27 EXT TRIG A (polarity insensitive)
28 EXT TRIG B (polarity insensitive)
29 IN 2A (polarity insensitive)
30 IN 2B (polarity insensitive)
31, 33 NC
32, 34 NC
36 NC
Outputs
21 OUT 1+
22 OUT 1-
23 OUT 2+
24 OUT 2-
25 OUT 3+
26 OUT 3-
Auxiliary Interface
35 TX AUX
37 RX AUX
38, 39 GND
Main Interface
RS232 RS485 Full-Duplex RS485 Half-Duplex
11, 15 TX232 TX485+ RTX485+
12, 16 RTS232 TX485- RTX485-
17 RX232 RX485+
18 CTS232 RX485-
10, 14, 19 GND_ISO GND_ISO GND_ISO
9, 13 RS485 Cable Shield RS485 Cable Shield
