MATRIX-2000™ QUICK GUIDE
8
Mechanical Installation:
M4 x 5 n°4
18.1
[0.71]
4
[0.16]
73
[2.87]
57
[2.24]
= =
28.1
[1.11]
57
[2.24]
121
[4.76]
57
[2.24]
M4 x 5 n°4
57
[2.24]
mm
[inch]
Overall dimensions - Standard model
73
[2.87]
121
[4.76]
57
[2.24]
mm
[inch]
73
[2.87]
Ø
4.
2
[
Ø
0
.
1
7]
15
[0.59]
37
[1.46]
4.2
[0.17]
95
[3.74]
47.5
[1.87]
Ø
8
.
2
[
Ø
0
.
3
2
]
47.5
[1.87]
95
[3.74]
2
[0.08]
mm
[inch]
Overall dimensions - 90° model Mounting Bracket Dimensions
