POWERSCAN
®
D8330/M8300/M8300-DK
16
2.10.2 Wall Mounting
1. Remove the yellow caps and insert the two wall mounting lock hinges provided
with your cradle.
2. Position the cables to be connected to the BC-80X0/C-8000 cradle along the
dedicated channels (see figures at page 14).
