Datalogic SG4 BASE - Page 29

SG4 BASE
29/73
Function Connection to Status
TEST
+24 VDC
Not connected or 0V
TEST ON
TEST OFF
RESET
+24 VDC
Not connected or 0V
RESET ON
RESET OFF
SELECT RANGE
+24 VDC
Not connected or 0V
SHORT (9 m)
LONG (19 m)
EDM
Normally closed
contact for a force-guided relay
-
ENABLE EDM
+24 VDC
Not connected or 0V
EDM OFF
EDM ON
MAN/AUTO RESTART SELECTION
OSSD1
OSSD2
AUTOMATIC RESTART
MANUAL RESTART
