15.13 (SE-SR2) SAFETY RELAY
MODEL DESCRIPTION CODE
SE-SR2 T
y
pe 4 safet
y
rela
y
- 3 NQ 1 NC 95ACC6170
The drawing show the connection between the safety light curtain and the Type 4 safety relay of the SE-SR2 series
operating in the automatic Restart mode.
Fig 70 - Safety relay
15.14 (CSME-03VU24-Y14) EDM RELAY BOX
MODEL DESCRIPTION CODE
CSME-03VU24-Y14 EDM Rela
y
95ASE1270
Fig 71 - EDM Relay
