Datalogic Touch TD1100

Technical Features
12 Touch TD1100
Technical Features
Item Description
Physical Characteristics
Color
Black; Other colors and custom logo options are available for minimum
quantity purchase.
Dimensions
Touch 65: 16.0 x 8.4 x 5.8 cm / 6.3 x 3.3 x 2.3 in
Touch 90: 17.0 x 10.4 x 6.7 cm / 6.7 x 4.1 x 2.7 in
Weight
Touch 65: 130.0 g / 4.6 oz
Touch 90: 153.0 g / 5.4 oz
Electrical Characteristics
Current
Operating (Typical): < 100 mA @ 5 VDC
Standby/Idle (Typical): 20 mA @ 5 VDC
Max 180mA @ 5VDC
Input Voltage 5 VDC +/- 0.5 V
Reading Performance
Imager Sensor Linear Imaging Sensor: Illumination: Red LED 640 nm wavelength
Print Contrast Ratio (Minimum) 25%
Read Angle Pitch: +/- 65º; Roll (Tilt): +/- 45º; Skew (Yaw): +/- 70º
Reading Indicators Beeper (Adjustable Tone); Good Read LED
Resolution
(1D Codes, Maximum)
Touch 65 Minimum Resolution = 4 mil (0.102 mm)
Touch 90 Min Resolution = 5 mil (0.127 mm)
Reading Ranges
Typical Depth Of Field Minimum distance determined by symbol length and scan angle.
Printing resolution, contrast, and ambient light dependent.
Touch 65 Touch 90
Code 39 5 mils: 0 to 5.0 cm (1.97 inches) 0-2.5 cm (0.98 inches)
Code 39 7.5 mils: 0 to 10.0 cm (3.94 inches) 0-8.5 cm (3.35 inches)
Code 39 10 mils: 0 to 15.0 cm (5.91 inches) 0-13.5 cm (5.31 inches)
EAN-13 13 mils: 0 to 20.0 cm (7.87 inches) 0-18.5 cm (7.28 inches)
