Datalogic Touch TD1100

Quick Reference Guide 1
Touch TD1100
Quick Reference Guide
The Touch™ TD1100 series of linear imaging contact readers represent the Datalogic
ADC solution for customers who require a cost-effective solution for close contact bar code
reading without sacrificing quality and performance.
Designed for low throughput applications within multiple markets, the Touch TD1100
readers provide the guarantee of contact reading with an excellent reading performance on
virtually all linear bar codes, including damaged or poorly printed codes.
Small, lightweight and low on energy consumption, the Touch TD1100 readers can still
provide robustness and a 1.5 m / 5.0 ft drop resistance, which is typically included in a high-
er range of products.
The Touch readers are available with the option of two different sizes of reading windows:
6.5 cm / 2.6 in (Touch 65) or 9.0 cm / 3.5 in (Touch 90), which benefits the user when
reading either standard or wide bar codes.
The Touch 65/90 Pro readers provide a complete all-in-one multi-interface solution, in-
cluding RS-232, USB, Keyboard Wedge, and Wand Emulation; the Touch Lite 65/90
readers provide USB-only or RS-232 / Keyboard Wedge interfaces.
Parts of the Reader
1
2
3
4
1. Indicator Window 3. Scan Window
2. Cable Release Hole 4. Trigger
