14 M-Class
4. Close the Printhead Assembly and press down until it
locks into place.
5. Route the ribbon up and then around to the Ribbon
Take-Up Hub, winding it several times in a clockwise
direction to secure it in place.
6. Close the cover and press the
FEED
button several times to position the ribbon and ensure proper tracking.
7. The ‘Media Type’ setting within the printer’s setup must be set to ‘Thermal Transfer’ to print using a ribbon;
Printers without front display: See section 4.5.2
Printers with front display: See section 5.1.2

Datamax Mark II M-4206 Specifications

General

Print Resolution	203 dpi
Type	Label Printer
Print Method	Thermal Transfer
Max Print Speed	6 inches per second
Memory	16 MB SDRAM, 8 MB Flash
Interfaces	USB, Serial, Parallel
Media Width	4.5 inches
Media Length	0.25" to 99"
Max Print Width	4.25 inches (108 mm)
