M-Class 25
21) INPUT MODE
Selects between the standard or template
interpretation of incoming data.
Possible Values:
* DPL (printer constructs the label using the
standard DPL commands)
LINE (printer constructs the label using a
preloaded template form)
22) DPL EMULATION
This instructs the firmware to process specific DPL data (Start of
Print, DPI, and Imaging function) according to the selected printer
emulation.
Possible Values:
* STANDARD
ALLEGRO (Allegro Emulation)
P PLUS (Prodigy Plus Emulation)
PRODIGY (Prodigy Emulation)
23) HEAT
Controls the ‘burn-time’ of the printhead. This is
the equivalent of Heat Setting on most label
software programs.
Possible Values:
Range: 0 – 30; default = *10
24) EXACT TIME
Instructs the printer to wait until the system is idle before the next
label’s data and time fields are formatted to eliminate any
discrepancy between the buffered and printed times.
Possible Values:
YES or NO; default = *NO
25) GPIO
Sets the printer’s option port to function for GPIO
applications, (see Appendix F for more
information).
Possible Values:
YES or NO; default = *NO
26) NO REPRINT
When a fault condtions is detected, printing stops and the ERROR
light turns on. After the problem is corrected, the FEED Key must
be pressed to clear the fault. The label in process is not reprinted.
Possible Values:
YES or NO; default = *NO
(NO = NO REPRINT” disabled, reprinting will occur.)
Note: All of the values for these Menu Items will be stored in non-volatile memory for future power-ups.
