DI-2008 Hardware Manual
Specifications
5
Minimum temperature measurement resolution: TC Type Resolution Units
J 0.086
°C
K 0.096
T 0.037
B 0.096
R/S 0.111
E 0.073
N 0.092
4-20 mA current loop resolution:
(5 VFS range with 250 shunt resistor)
13,100 ADC counts over the 4-20 mA range
Maximum sample throughput rate: Single enabled channel: 2 kHz
Two or more enabled channels: 200 Hz
Minimum sample throughput rate:
(Hardware)
1 enabled analog channel: 0.000109 Hz (1 sample every
9141.99 sec.)
2 or more enabled analog channels: 0.000011 Hz (1 sample
every 91419.93 sec.)
Minimum sample throughput rate:
(with WinDaq software)
.0001969 Hz
Sample rate timing accuracy: 50 ppm
Indicators, Connections, Controls
Interface: USB 2.0 (mini-B style connector)
Indicators (LED): Power, Active, Event
Input connections: Two 16-position terminal strips
Push button: Manual event when used with WinDaq software
Environmental
Operating temperature range: 0 to 70 °C
CJC range: -20 to 80 °C
Storage temperature: -20 to 80 °C
Storage humidity: 0 to 90 %RH, non-condensing
ChannelStretch™*
WinDaq software:
If any synced device has two or more enabled analog channels, all
synced devices must enable the same number of analog and digital
channels and the same sample throughput rate. If all synced devices
have one or zero enabled analog channels, sample rate per channel
must be the same across all devices.
Programmed (.Net- or protocol-based): Sample rate per channel must be the same across all synced
devices.
*One or more digital ports configured as a discrete input counts as one digital channel. Rate and count inputs count
as one digital channel each.
