DI-2008 Hardware Manual
Introduction
2
counts; Digital ports D4-D6 are general-purpose digital input ports. Please Note: Digital outputs are not supported in
WinDaq software. Each port may be configured as a switch using your own program.
Software
All software required to record and playback waveforms is included with the purchase of any DI-2108-P data acqui-
sition system via download.
WINDAQ
®
Recording and Playback Software
WINDAQ Acquisition and WINDAQ Waveform Browser allow you to record and playback data acquired through your
instrument. W
INDAQ software is an invaluable resource to record and analyze your data and is available for free from
our web site (www.dataq.com).
W
INDAQ Lite Data Acquisition software (free) can be used to record waveforms directly and continuously to disk
while monitoring a real time display of the waveforms on-screen. It operates, displays, and records all channels in
real time. An optional unlock code is available to allow you to synchronize multiple units and expand channel count
using ChannelStretch.
W
INDAQ Waveform Browser playback software (also known as “WWB”) offers an easy way to review and analyze
acquired waveforms. A built-in data file translator allows the user to display multiple waveforms acquired by
W
INDAQ Acquisition software or any of a wide range of data acquisition packages. The software’s disk-streaming
design allows data files of any length to be graphically displayed rapidly, in normal or reverse time directions. Seven
standard cursor-based measurements, frequency domain, and statistical analysis functions help simplify waveform
analysis and interpretation. W
INDAQ Waveform Browser is free and installed when installing WINDAQ Software.
Help
All WINDAQ software utilizes context-sensitive help. Help may be accessed through the Help menu or by pressing the
F1 key with any pull-down menu item selected. This will take you directly to the Help topic most relevant to that par-
ticular function or feature. Help topics discuss in detail each function available in the software.
