DP-50 / DP-50D / MP55-B - USERS MANUAL
Table 02 : Shop organization , 1 row and 9 fields
Field No Description Range Note
1 ECR logical number into the shop 1÷99 Default:1
2 Type of the service 0,3,4 0: Control of the store exit or the ECR
serves only one stand.
3: Configured to work with a scale of type
DATECS
4: Configured to work with a scale of type
ANGEL or DIBAL
Default: 0
Note: The ECR can manage a scale only if
it has RS232 interface.
3 Reserved
4 No passwords are used 0 or 1 0: The passwords usage is disabled
1: The passwords usage is enabled
Default: 0
5 Function of the key PLC in REG
mode
0 or 1 0: Sales by code ( e.g. the row number)
1: Print a number
Default: 0
6 Auto Power Off in REG mode
between the receipts
0 or 1 0:Disabled
1: In REG mode the ECR automatically
turning-off if there is no active receipt and if
30seconds expires with no activity; By
pressing “ОN”, the ECR restores its state
back to REG mode.
Default: 1
7 Clearing of the quantities and
turnovers of the items when a
daily Z report is made
0 or 1 0:Disabled
1:Enabled
Default: 1
8 Sales by PC request in REG
mode, programming between the
receipts in REG mode
0,1,2,3 0: Disabled
1: Enabled programming between the
receipts in REG mode.
2: Enabled sales by PC request in REG
mode.
3: Enabled both 1 and 2
Default: 0
Note: This field is meaningful only when the
value from filed 2 is set to 0
9 Communication speed 1,2,3,4 1: 4800 bps
2: 9600 bps
3: 19200 bps
4: 38400 bps (default)
Table 03 : Operator names and passwords
Each row keeps the settings for one operator and the row number is equal to the
operator number. The rows are 30 as are the maximal operators supported, fields: 2
Field No Description Range Note
1 Operators name up to 10 symbols Default: ОПЕРАТОРxx (e.g. OPERATORxx)
(xx-the operators number)
2 Operators password up to 8 digits Default: same as the operators number.
20
