11: Junction Board
11-8 PRC1099A-MS
L5 459032 “IND ASY,3T#30 MAGNET 1-490201”
L6 459263 “IND ASSY,8T#30GA MAG 1-490303”
L7 459263 “IND ASSY,8T#30GA MAG 1-490303”
PF1 550043 “FUSE,POLY RESISTOR 2.7 AMPS”
Q1 032004 “XSTR,MMBT2222A NPN SOT23”
Q2 032004 “XSTR,MMBT2222A NPN SOT23”
R1 018R22001 “RES, 0.22 OHM MF 1W 1% 2512”
R10 013242000 “RES,2.4K OHM 1/8W 5% TK 0805”
R11 013102000 “RES, 1K OHM 1/8W 5% TK 0805”
R12 013102000 “RES, 1K OHM 1/8W 5% TK 0805”
R13 013102000 “RES, 1K OHM 1/8W 5% TK 0805”
R14 013102000 “RES, 1K OHM 1/8W 5% TK 0805”
R15 013162100 “RES, 1.62K OHM 1/8W 1% TK 0805”
R2 013392000 “RES,3.9K OHM 1/8W 5% TK 0805”
R3 013562000 “RES,SM,CF,5.6K,0.1W,5%,0805”
R4 170223 “RES,5K TRIMMER”
R5 170339 “RES,500 OHM,VAR,MINI,SIDE ADJ”
R6 013471000 “RES, 470 OHM 1/8W 5% TK 0805”
R7 013103000 “RES,10K OHM 1/8W 5% TK 0805”
R8 013103000 “RES,10K OHM 1/8W 5% TK 0805”
R9 013102000 “RES, 1K OHM 1/8W 5% TK 0805”
TP1 620035 JACK TEST MINI HORIZONTAL
TP2 620035 JACK TEST MINI HORIZONTAL
TP3 620035 JACK TEST MINI HORIZONTAL
TP4 620035 JACK TEST MINI HORIZONTAL
TP5 620035 JACK TEST MINI HORIZONTAL
U1 330191 “IC,MC34063PI,SWPS CTLR,DIP8”
U2 330340 “IC, LM317AT VREG ADJ 1A TO-220”
Table 11-3 Junction Board Parts List (009-00901 Rev. W)
Designator Part Number Description
