11: Junction Board
PRC1099A-MS 11-7
Table 11-3 Junction Board Parts List (009-00901 Rev. W)
Designator Part Number Description
C1 022476006 “CAP, 47UF TA 35V 20% 7343-43”
C10 021476000 “CAP, 47UF 20%, 16V, X5R, 1210”
C11 021103000 “CAP, 0.01UF X7R 50V 5% 0805”
C12 022476006 “CAP, 47UF TA 35V 20% 7343-43”
C13 021476000 “CAP, 47UF 20%, 16V, X5R, 1210”
C15 021103000 “CAP, 0.01UF X7R 50V 5% 0805”
C16 021106006 “CAP, 10UF X7R 25V 10% 1210”
C17 021103000 “CAP, 0.01UF X7R 50V 5% 0805”
C18 021103000 “CAP, 0.01UF X7R 50V 5% 0805”
C19 021106003 “CAP, 10UF X7R 10V 10% 0805”
C2 021103000 “CAP, 0.01UF X7R 50V 5% 0805”
C20 021103000 “CAP, 0.01UF X7R 50V 5% 0805”
C21 021225003 “CAP, 2.2UF X7R 25V 10% 0805”
C22 021470003 “CAP, 47PF, NP0, 100V, 2%, 0805”
C3 022476007 “CAP, 47UF TA 10V 20% 3528-21”
C4 022476007 “CAP, 47UF TA 10V 20% 3528-21”
C5 021104000 “CAP, 0.1UF X7R 25V 5% 0805”
C6 021104000 “CAP, 0.1UF X7R 25V 5% 0805”
C7 021104000 “CAP, 0.1UF X7R 25V 5% 0805”
C8 021104000 “CAP, 0.1UF X7R 25V 5% 0805”
C9 022476006 “CAP, 47UF TA 35V 20% 7343-43”
D1 037702014 “DIODE,B260 SCHOTTKY 2A 60V SMB”
D2 037702014 “DIODE,B260 SCHOTTKY 2A 60V SMB”
D3 320433 “DIODE, 1N6373 ZNR TVS 6V 1500W”
J1 610280 “HEADER, 2X10 PIN MLX RT ANG”
J2 610280 “HEADER, 2X10 PIN MLX RT ANG”
J3 610211 “HEADER,MLX,4PIN,.156,POLAR”
L1 459241 “IND ASSY,20T#28 AWG 1-490061”
L2 459032 “IND ASY,3T#30 MAGNET 1-490201”
L3 459032 “IND ASY,3T#30 MAGNET 1-490201”
L4 459263 “IND ASSY,8T#30GA MAG 1-490303”
To Next Page
