14: Maintenance
14-6 PRC1099A-MS
14.3.2 Board Locations
This section provides the location of boards inside the PRC1099A chassis.
Figure 14-4 Radio Case Removal
Battery
Box
Transceiver
Case
Clamp
Captive
Screws
Captive
Screws
Figure 14-5 Board Locations (Top)
