Datron PRC1099A - Page 90

5: Mixer Board
PRC1099A-MS 5-17
Table 5-4 Mixer Board Parts List (009-00301 Rev. AU)
Designator Part Number Description
C1 210330 “CAP,33 PF DISC NP0”
C10 221201 “CAP, 200PF MICA 100V 5% DM5”
C11 221101 “CAP, 100PF MICA 300V 5% DM5”
C12 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
C13 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C14 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
C17 261500 “CAP, 50PF 5MM TRIMMER”
C18 210050 “CAP, 5PF NP0 50V 0.25P 0.1LS DSK”
C19 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C2 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C20 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C21 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C22 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C23 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C24 261250 “CAP, 30PF 5MM TRIMMER”
C25 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C27 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C28 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
C29 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
C3 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C30 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
C31 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
C33 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C34 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C35 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C36 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C38 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C39 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C4 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C40 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C42 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
C43 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
