5: Mixer Board
PRC1099A-MS 5-21
Q12 031100023 “XSTR, MMBT3904, NPN, 40V, 0.2A, SOT23-3”
Q13 031101008 “XSTR, SMT MMBT3906 PNP SOT-23”
Q2 031100023 “XSTR, MMBT3904, NPN, 40V, 0.2A, SOT23-3”
Q4 031100023 “XSTR, MMBT3904, NPN, 40V, 0.2A, SOT23-3”
Q5 310138 “N-MOSFET, VN2222LL, 150MA, 60V, TO92”
Q7 031102017 “MOSFET-N, BF998 DUAL-G SOT-143”
Q8 031102017 “MOSFET-N, BF998 DUAL-G SOT-143”
Q9 031100023 “XSTR, MMBT3904, NPN, 40V, 0.2A, SOT23-3”
R1 113562 “RES,5.6K OHM 1/8W CF 5%”
R12 113222 “RES,2.2K OHM 1/8W CF 5%”
R13 DNP “NULL PART, VACANT PCB LOCATION”
R14 113223 “RES,22K OHM 1/8W CF 5%”
R15 113682 “RES,6.8K 1/8W 5% CARBON FILM”
R16 113222 “RES,2.2K OHM 1/8W CF 5%”
R17 113103 “RES, 10K OHM 1/8W CF 5%”
R18 113153 “RES,15K OHM 1/8W CF 5%”
R2 113153 “RES,15K OHM 1/8W CF 5%”
R20 113221 “RES,220 OHM 1/8W 5% CF”
R21 113103 “RES, 10K OHM 1/8W CF 5%”
R22 113103 “RES, 10K OHM 1/8W CF 5%”
R23 113472 “RES, 4.7K OHM 1/8W CF 5%”
R24 113221 “RES,220 OHM 1/8W 5% CF”
R25 113102 “RES, 1K OHM 1/8W CF 5%”
R26 113334 “RES, 330K OHM, 1/8W, 5%, CF”
R27 113271 “RES,270 OHM 1/8W 5% CF”
R28 113153 “RES,15K OHM 1/8W CF 5%”
R29 113332 “RES,3.3K OHM 1/8W CF 5%”
R3 113223 “RES,22K OHM 1/8W CF 5%”
R30 113223 “RES,22K OHM 1/8W CF 5%”
R31 113101 “RES,100 OHM 1/8W CF 5%”
R32 113104 “RES,100K OHM 1/8W CF 5%”
R33 113103 “RES, 10K OHM 1/8W CF 5%”
Table 5-4 Mixer Board Parts List (009-00301 Rev. AU)
Designator Part Number Description
To Next Page
