Datron PRC1099A - Page 95

5: Mixer Board
5-22 PRC1099A-MS
R34 113101 “RES,100 OHM 1/8W CF 5%”
R35 113221 “RES,220 OHM 1/8W 5% CF”
R36 113104 “RES,100K OHM 1/8W CF 5%”
R37 170110 “POT,500 OHMS CARBON 10MM VERT”
R38 113103 “RES, 10K OHM 1/8W CF 5%”
R39 113122 “RES,1.2K OHM 1/8W CF 5%”
R4 113821 “RES,820 OHM 1/8W CF 5%”
R40 113102 “RES, 1K OHM 1/8W CF 5%”
R41 113471 “RES,470 OHM 1/8W CF 5%”
R42 113821 “RES,820 OHM 1/8W CF 5%”
R43 113222 “RES,2.2K OHM 1/8W CF 5%”
R44 113470 “RES,47 OHM 1/8W 5% CARBON FILM”
R45 113680 “RES,68 OHM 1/8W 5% CF”
R46 113222 “RES,2.2K OHM 1/8W CF 5%”
R47 DNP “NULL PART, VACANT PCB LOCATION”
R48 DNP “NULL PART, VACANT PCB LOCATION”
R49 DNP “NULL PART, VACANT PCB LOCATION”
R5 113470 “RES,47 OHM 1/8W 5% CARBON FILM”
R50 DNP “NULL PART, VACANT PCB LOCATION”
R51 DNP “NULL PART, VACANT PCB LOCATION”
R52 DNP “NULL PART, VACANT PCB LOCATION”
R53 DNP “NULL PART, VACANT PCB LOCATION”
R54 113333 “RES,33K OHM 1/8W CF 5%”
R55 113104 “RES,100K OHM 1/8W CF 5%”
R56 113154 “RES,150K OHM 1/8W CF 5%”
R57 113103 “RES, 10K OHM 1/8W CF 5%”
R58 113222 “RES,2.2K OHM 1/8W CF 5%”
R6 113222 “RES,2.2K OHM 1/8W CF 5%”
R60 113680 “RES,68 OHM 1/8W 5% CF”
R61 113510 “RES,51 OHM 1/8W 5% CARBON FILM”
R65 113271 “RES,270 OHM 1/8W 5% CF”
R66 013101000 “RES,100 OHM 1/8W 5% TK 0805”
Table 5-4 Mixer Board Parts List (009-00301 Rev. AU)
Designator Part Number Description
