5: Mixer Board
PRC1099A-MS 5-23
R67 013101000 “RES,100 OHM 1/8W 5% TK 0805”
R68 013000000 “RES, ZERO OHM, 2A, TK, 0805”
R8 113101 “RES,100 OHM 1/8W CF 5%”
T1 459033 “IND ASSY,4T1T#30 MAG 1-491301”
T2 459034 “IND ASSY,1T3T#30 MAG 1-491301”
T3 420018 INDUCTOR IF 1650KHZ
T4 459034 “IND ASSY,1T3T#30 MAG 1-491301”
U1 380010 “IC, MAR-8 RF AMPLIFIER MICRO-X”
U2 330006 “IC, MC1496P BAL DE/MOD DIP14”
U3 330343 “IC, LM317LZ ADJ VREG 100 MA TO-92”
U4 033306042 “IC, BL051 RF AMP 4GHZ SOT89”
XY1 868000 “GASKET,EMI,.125 X 0.156”
Y1 370007 CRYSTAL FILTER 75MHZ 4 POLE
Table 5-4 Mixer Board Parts List (009-00301 Rev. AU)
Designator Part Number Description
