1.b Physical Layout
1.7
Analog Output
Connector
(see Fig. 10)
1
O
Analog Input
Connector
(see Figs. 5, 6)
Logic I/O
Connector
(see Figs. 4, 9)
ON-OFF
Switch
Fuse
AC Power
Connector
Connector
for Optional
Keyboard
Voltage
Selector
Switch
RS-232-C
Interface
Connector
(see App. B)
Panel-
Mount
Clamp
Screw
Fig. 2(a) 4077 Rear Panel (AC Power)
