Study the following diagrams to acquaint yourself with your 4077's most
important front and rear elements.
Physical Layout 1.b
1.6
psi
lb-ft
Bargraph
Low Endpoint
(LEP)
"Low-Low" Limit
(LLL)
Setup and Special
Function Buttons
Engineering-
Unit Legends*
Channel No.
and
Mnemonic
Display
lbs
SET
UP
Bargraph
High Endpoint
(HEP)
"High-High" Limit
(HHL)
"Low" Limit
(LOL)
"High" Limit
(HIL)
Button
"RUN-TIME
FUNCTION"
Indicators*
Button Activity
Indicator
ON
LINE
F1 F2 F4
SET
UP
F3 F5
* Standard film shown.
(F1 = LIVE DISPLAY
F2 = [NOT USED]
F3 = TARE
F4 = MAX/MIN/MAX-MIN STEP
F5 = MAX/MIN RESET
—see Section 3)
CHAN STEP
44000
Fig. 1 4077 Front Panel
