B.3
4077/Computer RS-232-C Connections App. B
25-Pin RS-232-C
Connector
2
3
4
5
8
2
3
4
5
7
20
RECEIVE
TRANSMIT
DTR
COMMON
CTS
TRANSMIT
RECEIVE
RTS
CTS
COMMON
DTR
COMPUTER
NO HANDSHAKE
4000 Instrument
11(c)
9-Pin RS-232-C
Connector
2
3
4
5
8
2
3
4
5
6
8
RECEIVE
TRANSMIT
DTR
COMMON
CTS
RECEIVE
TRANSMIT
DTR
COMMON
DSR
CTS
COMPUTER
4000
Instrument
Fig. 12 Suggested RS-232-C Interface Connections
(to 9-Pin RS-232-C Connector)
