Key to Cable Identification
If you are reading a colour print or a soft copy of this manual, cable types shown
in figures can be identified from Table 11.
Cable Type Colour / Style
XLR Analogue Brown, solid
RCA Phono Analogue Brown, long dash
XLR Digital (AES3) Blue, solid
BNC Digital Pale blue, solid
RCA Phono Digital (SPDIF) Pale blue, short dash
Optical (SPDIF) Dark magenta, solid
IEEE 1394 Red, solid
Sync Link Green, solid
Wordclock Dark green, solid
AES Reference Dark green, long dash
GPS Reference Dark green, short dash
RS-232 Purple, solid
Table 11 – Cable colours and styles
Where more than one cable of any type is used in a drawing, they can be
identified by a coloured sleeve at the source and a coloured arrow head at the
destination.
