※ Components of the Cycle: Compressor, condenser, capillary tube and evaporator (cooler)
4 Steps of the Refrigeration Cycle: Compression →Condensation →Expansion →Evaporation
※ Flowchart Liquid refrigerant evaporates in the evaporator and becomes low pressure,low temp.
→Absorb heat from the refrigerator →The compressor absorbs the gas
refrigerant →Send the high temp & pressure gas to the condenser →The condenser transfers
the heat from the compartments and the heat generated during the compression cycle, and
becomes liquid. →It reduces its pressure in the capillary tube. →It goes into the evaporator,
repeating the above cycle.
REFRIGERATION CYCLE
2-1
BASIC REFRIGERATION CYCLE
