Self Diagnosis
6
Case Output Terminal
(The Main PCB and the Case Output Terminals are connected with wire connectors.)
*Test the terminals on the PCB Case to check for voltage or operation related
errors concerning QUEEN PJT.The terminal composition is shown in the diagram.
If an error is found while testing the above terminals and the housing connectors,check the
inside of the PCB Case.
⇒The following descriptions are based on the PCB Case.
