29
1) Machine Compartment Fan Motor Delay Function
● This refrigerator is programmed to control its temperature automatically inaccordance with the ambient
temperature.The Compressor Cooling Fan (Machine Compartment Fan)is controlled according to the
ambient temperature.
※ Refer to the bleow for ambient temp range and cooling fan operation.
Machine Compartment
Delay
Temperature Range
Above 51.8℉(11℃)
Between 46.4℃(8℃) and 50℃(10℃)
Below 44.6℉(7℃)
Load Operation State
With the COMP on, Fan will be on immediately
After 5 minutes of the Comp On, Fan will be on
Comp will be on and Fan will be off
① INITIALIZATION(INITIAL POWER ON)
It is an operation for checking that the ice maker is good after the initial power on.
1) When the power is applied for the first time, the ejection arm will be rotated by rotating the Ice eject motor
clockwise.
2) During the ejection arm rotating, supply water for 0.5 seconds.
※ SUMMARY
Power on → Ice maker finds horizontal position → Stand by for 46 minutes → After 46 minutes it will check
the ice temp → If ice tray temp is OK, it will eject the initial ice cubes.
Power Switch
Red Power LED
Feeler Arm
2) ICE-MAKER Function
4
ARRANGEMENT AND ADJUSTMENT
